1. Speed 150 meters/minutes

2. Drying tunnel 8 meters, 4 sections, external heating

3. 4 air inlet fans (1.5 kW)

4. 4 exhaust fans, hot air recycling for secondary use

5. The protective roller in the drying tunnel is driving roller and rotates the synchronous belt

6. Anilox roller coupling 1 piece 120 mesh installed with machine

7. Bass drum has built-in oil heating

8. Dual position automatic tension for rewinding

9. Front feeding dual-position ultrasonic edge correction and automatic tension

10. Dual-position ultrasonic edge correction and automatic tension for rear lowering material

11. Automatic tension for rear loading and unloading (no edge correction)

12. 1 piece of rubber roller under the big drum installed

13. Edge correction at the drying tunnel exit

14. Automatic tension touch screen PLC control for retracting and unwinding materials

15. There are 4 air expansion shafts in total and 1 head shaft.

16. Scraper dual air pressure motor action

17. The big drum motor and anilox roller motor are synchronized, and the swing arm is controlled by double frequency converters.

19. 2 frequency conversion motors for collecting materials

20. 1 pneumatic glue pump

21. 1 glue tray

22. The air expansion shaft for retracting and releasing materials moves left and right 20mm

The total power is 80 kW, the total length is 9 meters, the height is 3.2 meters, the width is 2.2 meters, and the total weight is 6 tons. The rubber rollers on the anilox rollers are polyurethane wdith 800 and 1300, 2 pieces each width.
