The electrical control system adopts imported PLC control, and the operation interface adopts touch screen, which can set working parameters and display operation conditions on the screen.
Unwinding adopts hydraulic lifting, hydraulic width adjustment, servo motor active unwinding, 3-belt 6-mechanical expansion head, automatic tension control;
Take up hydraulic lifting, servo motor take-up, adjustable width, roll take-up, mechanical head tension.
The system has the functions of meter counting, coil diameter calculation, meter number automatic shutdown, etc.
The system has perfect mechanical, electrical, gas and hydraulic integrated design, and takes complete safety protection measures.
